Single lip dust ring: This type of dust ring provides a highly technical and precise partition in the cylinder without screws and brackets, tight tolerances, no metal inserts and no corrosion.

Applied range: Suitable for axial action of hydraulic and pneumatic cylinders, pistons and rod guides in piston rods.

Single lip dust ring: This type of dust ring provides a highly technical and precise partition in the cylinder without screws and brackets, tight tolerances, no metal inserts and no corrosion.

Applied range: Hydraulic cylinders and cylinders, plungers and bushings and other axial motion occasions.

Single lip dust ring: This type must be pre-greased before installation. The diameter of the interference fit ensures a tight fit in the groove, thus protecting against foreign intrusions and moisture.

Applied range: Axial action of the pneumatic cylinder, piston and rod guide in the piston rod.

Single lip dust ring: This typeofdust ring relies on a pressure-matched metal shell pressed against the outer channel of the sealing chamber, and the dust ring is firmly fixed in the axial open installation position. Suitable for harsh working conditions.

Applied range: Hydraulic cylinders and valves.

Double lip dust shield: No special screws and brackets are required for installation, no strict tolerances are required, and no metal inserts are required. The dust ring is continuous and can be easily inserted into the groove.

Applied range: Piston rod lifting device for axial movement in hydraulic, and pneumatic cylinders, and piston rod guide.

Double lip dust shield: This type of dust shield consists of a teflon dust shield and a pre-loaded O-ring. A combination of slip rings (polytetrafluoroethylene) and O-rings (elastic materials), with a variety of compounds to choose from.

Applied range: Suitable for a wide range of applications, especially in corrosive media and/or high temperatures.

The utility model relates to a lip seal made of polyurethane material. It can be used in various occasions where the performance of ordinary rubber or fabric reinforced rubber does not meet the requirements.

Applied range: Mainly used in heavy duty walking machinery or industrial hydraulic plunger or piston rod seal.

Polyurethane U-shaped construction with a second seal lip. For high pressure applications and harsh operating conditions. In some cases can replace the two seals used in series configuration.

Applied range: Mainly used in heavy duty walking machinery or industrial hydraulic plunger or piston rod.

A compact seal, the O-ring ensures pre-compression of the lip under low pressure or vacuum conditions, and a strong seal structure for harsh working conditions.

Applied range: Mainly used in heavy duty walking machinery or industrial hydraulic plunger or piston rod.

Compact seal design with two seal lips and an anti-squeeze retaining ring. Enhanced sealing performance under zero pressure conditions.

Applied range: Mainly used inheavy duty walking machinery or industrial hydraulic plunger or piston rod.

Compact seal with extrusion-resistant retaining ring, resistant to high pressure or extreme peak pressure, and very wear-resistant. It is commonly used as a buffer element in rod seal systems to protect secondary seals from high pressure and impact loads.

Applied range: Mostly used in walking hydraulic industry.

The hydraulic cylinder is sealed by a unidirectional combined rod, which is composed of a polytetrafluoroethylene slip ring and an O-ring as a force element. Good sealing performance, but only requires a small assembly space. For low friction, high pressure applications.

Applied range: Hydraulic cylinder rod with combination seal.Especially suitable for control cylinders, servo cylinders, machine tool cylinders and high speed cylinders.

It is a double-acting combined seal composed of a polytetrafluoroethylene slip ring and an elastomer material O-ring as a force element. Multiple material combinations are suitable for a wide range of applications, especially in the face of harsh media and high temperatures.

Single-acting, U-shaped design of rubber material. Although the cross section and height of the seal are small, because the contact area of the sealing surface is very short, the friction is low, and no retainer or support is required. Used in pneumatic systems for lubrication.

Applied range: Recommended for plungers, piston rods, valve stems, and valve stems.

Piston rod seal for gas springs, with small size, long service life, low friction characteristics. Also suitable for hydraulic and pneumatic equipment with the same requirements.

Applied range: Suitable for gas springs, piston rods, and valve rods, but also for slow rotating devices.

Used for internal dynamic seals on reciprocating piston rods. Polytetrafluoroethylene seal with pre-compressed spring, short axial size design.

Applied range: Suitable for reciprocating piston rod seal.

It is a piston rod seal, as an internal dynamic seal on the reciprocating piston rod. Polytetrafluoroethylene seal with pre-compressed spring, resistant to high pressure.

Applied range: Suitable for reciprocating piston rod seal.

V-type piston rod seal, single acting. It consists of multiple V-shaped seals, a support ring and a retaining ring. The number of V-rings ranges from 3 to 10, and 5 V-rings are recommended.

Applied range: Mainly used for large diameter heavy duty cylinder, can also be used in hydraulic engineering actuator.

Piston seal for hydraulic cylinders, single acting, polyurethane U-shaped design for high pressure applications. Robust seal construction for harsh operating conditions.

Applied range: Mainly used in heavy duty walking machinery or industrial hydraulic piston.

Single acting, rubber U-ring. Although the cross section and height are small, but the sealing performance is good, no retainer or support. Suitable for non-lubricated pneumatic systems.

Applied range: Mainly used in hydraulic piston and cylinder.

The single-acting piston seal consists of a polytetrafluoroethylene piston seal ring and an elastic material O-ring as a pre-load. Low friction for high pressure applications.

Applied range: Suitable for use in single-acting pistons such as control cylinders, servo control systems, machine tools, quick response and steering cylinders.

The double-acting piston seal consists of a polytetrafluoroethylene piston seal ring and an elastic material O-ring as a pre-load. Low friction for high pressure applications.

Applied range: Suitable for use in double acting pistons such as control cylinders, servo control systems, machine tools, fast response and steering cylinders.

Compact seal, O-ring ensures pre-compression of the lip under low pressure or vacuum conditions, strong seal structure for harsh working conditions.

Applied range: Mainly used in heavy duty walking machinery or industrial hydraulic plunger or piston rod.

Piston seal for hydraulic cylinders, single acting, polyurethane U-ring with retaining ring for high pressure applications. Robust seal construction for harsh operating conditions.

Applied range: Mainly used in heavy duty walking machinery or industrial hydraulic piston.

Double acting seal, slip ring design. Has excellent wear resistance, easy to install on the single piston. It is not sensitive to peak pressure and has very high extrusion resistance.

The double-acting seal consists of a rubber sealing element, two retaining rings and two guiding rings. Good wear resistance, can be easily installed on the single piston.

Applied range: Suitable for presses, drive cylinders, industrial support and operating cylinders, and walking hydraulics.

Suitable for reciprocating piston seal, polytetrafluoroethylene seal with pre-compressed spring, short axial size design.

Applied range: Suitable for reciprocating piston seal.

Piston seal, reciprocating rod on the outside dynamic seal. Polytetrafluoroethylene seal with pre-compressed spring, resistant to high pressure.

Applied range: Suitable for reciprocating piston seal.

It is composed of wear-resistant low friction sliding ring and rubber O-ring. It is mainly used in places where the pressure alternates from one side of the seal to the other, such as rotary track mandrel, rotary joint, hose twister, machine tool hydraulics.

Rotary combination seal for rotary dispensers. The outer diameter is used as the dynamic seal of the sealing surface. Double acting, sealing surface/slip ring design of PTFE. Low friction for high pressure sealing applications.

Guide ring, a wide selection of materials and cuts.

Guide ring, a wide selection of materials and cuts.

导Guide belt, a variety of materials and cut options, can be tailored to the required length.

Guide belt, a variety of materials and cut options, can be tailored to the required length.
